Fiber Distribution Box GFX-13
|
|
|
Material
|
PC+ABS
|
|
Size(mm)
|
345*220*95
|
|
Optical Cable Ports
|
2*φ18mm
|
|
Max Capacity
|
24 Cores
|
|
Description
|
SC - 24 Ports
|
|
Opration Temperature
|
-40°C-+85°C
|
|
Installation Way
|
Wall Mounting/Holding pole
|
|
Specification
|
||
|
Environmental Requirement
|
Working temperature
|
-40℃~+85℃
|
|
Relative humidity
|
≤85%(+30℃)
|
|
|
Atmospheric pressure
|
70KPa~106Kpa
|
|
|
Thunder-proof Technical Data
|
The grounding device is isolated with the cabinet, isolation resistance is no less than 2 104 MΩ/500V (DC);IR≥2 104 MΩ/500V
|
|
|
The withstand voltage between grounding device and cabinet is no less than 3000V (DC )/min, no puncture,no flashover; U≥3000V
|
||
